CN-ODC Cabinet Cooling

• 1.Good design, stable structure and easy maintenance.
• 2.Widely used for outdoor telecommunication cabinets,battery cabinets, electric cabinets and industry control cabinets etc.
• 3.Door mounted, side mounted and top mountedavailable.
• 4.The protective level is IP55, can protect cabinet frommoisture, dust and water. It can be installed indoor and outdoor, run at high ambient temperature of 55℃.
• 5.Digital temperature controller and high precision of temperature control.
• 6.The main components have CE certifications, which can meet EU RoHS requirements.

Characteristics

• Structure of compact and reasonable design, including door-mounted, side-mounted and top-mounted air conditioning series.
• Input voltage range: DC48V.
• The protection level of internal and external circulation reaches IP55 level, with dustproof and waterproof function, so it can be installed in indoor and outdoor use.
• Can be operated under high temperature working conditions of 55°C/55°C.
• Digital temperature controller with high precision temperature control.
• The product meets the requirements of EU RoHS and is CE certified.





Installation Drawin

Dimension & Install Steps:

• 1.Measure the required dimension on the pending installed cabinet door.
• 2.Cutted the dimension and holes for the air condtioner.
• 3.Installation with screws,adding the gasket and glue for waterproof.
